HB Unit 5 Exam 2021

Last updated over 5 years ago

30 questions

1

ELA 5.2B

1

4

6

5

Library

HB Unit 5 Exam 2021

Last updated over 5 years ago

30 questions

1

ELA 5.2B

1

4

In your own words, describe why this flower shown here is seen as red. Use all appropriate vocabulary.

4

Describe one possible reason that you learned in class as to why there are such brilliant colors in the fall foliage. Be specific and use all appropriate vocabulary.

6

Rubisco is an important enzyme in photosynthesis. In your own words, describe
- WHERE it is
- WHAT it does
- what its SUBSTRATE and PRODUCTS would be

6

The rate of photosynthesis varies as factors such as temperature, light intensity and carbon dioxide levels change.
1. Explain why higher temperatures do not always translate into highest rates of oxygen production - 2 pts
2. The graph below represents the rate of photosynthesis as temperature increases, at both high light intensity and low light intensity. According to the data provided, within THIS temperature range shown here, which appears to have a more limiting effect on the rate of photosynthesis - light or temperature? EXPLAIN your answer using data/trends from the graph to justify your answer. - 4 pts

5

Some flowers self-pollinate, and some cross-pollinate. Define each. What is the benefit to the plant of cross-pollination?

Which of the following best describes how oxygen gas is produced during photosynthesis?

Oxygen gas is produced by the hydrolysis of ATP and NADPH during the Calvin Cycle

Oxygen gas is produced by Photosystem II, when water is split to extract H+ and electrons

Oxygen gas is produced by the fixation of carbon dioxide by rubisco during the Calvin Cycle

Oxygen gas is produced when G3P molecules are combined to make other organic molecules.

Which of the following statements best explains how the energy in a photon of light is stored in a molecule of the sugar G3P?

Light energy energizes electrons to make ATP and NADPH, which provide energy to produce G3P in the Calvin cycle.

Light energy directly provides energy to ATP synthase, which produces ATP during the light reactions.

Light energy directly provides energy to RuBP and CO2, which produce G3P in the Calvin cycle.

Light energy energizes electrons to make G3P, which provide energy to produce ATP and NADPH in the Calvin cycle.

Chemiosmosis in chloroplasts involves which of the following processes?

diffusion of electrons through the thylakoid membrane

reduction of water to produce oxygen

establishment of a proton gradient across the thylakoid membrane

formation of glucose from carbon dioxide

Use the figure and the compounds labeled A, B, C, D, and E to answer the following question.
Which best describes where the ATP for Phase 3 most likely comes from?

oxidative phosphorylation

glycolysis

cyclic photophosphorylation

linear photophosphorylation

What is the primary function of the Calvin cycle?

to produce oxygen by oxidizing water

to regenerate ATP for use in the light reactions of photosynthesis

to produce carbon dioxide for use in the light reactions of photosynthesis

to produce simple sugars from carbon dioxide

An early step in the process of carbon fixation combines three molecules of CO2 with three molecules of RuBP to produce three 6-carbon molecules, which are immediately converted to six 3-carbon molecules. These six molecules are phosphorylated and reduced to produce glyceraldehyde 3-phosphate (G3P). What additional events occur to complete the Calvin cycle?

release of two G3P to make sugars and regeneration of ATP from ADP

release of one G3P to make sugars and regeneration of RuBP

release of one G3P to make sugars and regeneration of citrate

release of one G3P to make sugars and regeneration of NADPH from NADP+

The figure shows the absorption spectrum for chlorophyll a and the action spectrum for photosynthesis. What colors of light are least effective would not be used for photosynthesis?

green-yellow

violet blue

yellow-orange

orange-red

Leo hikes in the woods. He finds a pine cone on the bike trail. What can Leo conclude about the type of plant that produced the cone?

It is a vascular plant

It is a Pterophyte

It is an angiosperm

It is a bryophyte

Which of the following is not a type of vascular plant?

gymnosperms

ferns

mosses

angiosperms

Bryophytes are_________________plant.

Seeded

Non-Vascular

Vascular

Flowering

What classification do these orquids belong to?

gymnosperm

angiosperm

fern

bryophytes

The visible spectrum is from just under 400 nm to just over 700 nm. What type of waves would have wavelengths longer than 700 nm?

radio and gamma waves

microwaves and infrared

infrared and ultraviolet

x rays and gamma waves

#8 is collectively known as ___________________________. It is where most of the photosynthetic activity takes place.

The role of the part labeled #1 is

to perform photosynthesis

to allow gas exchange

to release water through epidermal cells

to capture light energy

to prevent the release of water through the epidermal cells

This is an image of a chloroplast. What is #6 pointing to?

grana stack

cytoplasm

stroma

thylakoids

Above is an image of a thylakoid. A and C are the photosystems, as shown by the green pigments on their surface. E is where hydrogen ions DIFFUSE down their gradient. E is therefore the

NADP reductase

Rubisco

ATP synthase

Electon Transport Chain

When NADPH becomes NADP+, the energy released is provided to the molecules of the Calvin Cycle to power the reactions there. It would be most appropriate to say that

NADP+ got reduced at the Calvin Cycle

NADP+ got oxidized at the Calvin Cycle

NADPH got oxidized at the Calvin Cycle

NADPH got reduced at the Calvin Ccyle

What accurately describes the flow of the H+ from water?

water --> photosystem II --> photosystem I --> NADPH

water --> Calvin cycle --> photosystem II --> ATP synthase

water --> photosystem I --> photosystem II --> NADPH

water --> photosystem I --> NADPH --> photosystem II --> G3P

Which part would be considered a female part of the flower? Choose all that apply

In which part of the flower would you find a male gamete? Give the most specific answer.

Which part of the flower would eventually become a fruit?

The oxygen atoms that end up in G3P or other glucose derivitives came from which molecule?

CO2

H2O

RuBP

NADPH

Which statements best describes why plants perform both cyclic and noncyclic photophosporylation

The plant can choose which set of reactions to follow, based on environmental conditions like wind or drought.

Different types of plants perform the different reactions - some plants would perform cyclic, while others have evolved to perfom non-cyclic reactions.

Extra ATP is needed, above the amounts created by non-cyclic light dependent reactions

Extra NADPH is needed, above the amounts creatd by the non-cyclic light dependent reactions

In the vascular bundle of a plant you would find specialized cells for water transport and specialized __ cells for sugar transport.

Photosynthesizes have evolved to have more than one type of pigment molecule. Why was this an advantage for?

It was not an advantage, it happened accidentally and does not provide an advantage.

Since pigment molecules are broken down to harness their potential energy for the dark reactions of photosynthesis, the more pigment molecules the plant has the more sugar it can make.

Having accessory pigments increases the range of wavelengths and thus energy a plant can get from the suns’ radiation.

Chlorophyll is a very weak molecule that only absorbs green wavelengths, so plants require accessory pigments otherwise they would not be able to create enough food to survive.

This is a false statement, each type of organisms has one type of pigment molecule.

In your own words, describe why this flower shown here is seen as red. Use all appropriate vocabulary.

Describe one possible reason that you learned in class as to why there are such brilliant colors in the fall foliage. Be specific and use all appropriate vocabulary.

Rubisco is an important enzyme in photosynthesis. In your own words, describe
- WHERE it is
- WHAT it does
- what its SUBSTRATE and PRODUCTS would be

The rate of photosynthesis varies as factors such as temperature, light intensity and carbon dioxide levels change.
1. Explain why higher temperatures do not always translate into highest rates of oxygen production - 2 pts
2. The graph below represents the rate of photosynthesis as temperature increases, at both high light intensity and low light intensity. According to the data provided, within THIS temperature range shown here, which appears to have a more limiting effect on the rate of photosynthesis - light or temperature? EXPLAIN your answer using data/trends from the graph to justify your answer. - 4 pts

Some flowers self-pollinate, and some cross-pollinate. Define each. What is the benefit to the plant of cross-pollination?

Which of the following best describes how oxygen gas is produced during photosynthesis?

Oxygen gas is produced by the hydrolysis of ATP and NADPH during the Calvin Cycle

Oxygen gas is produced by Photosystem II, when water is split to extract H+ and electrons

Oxygen gas is produced by the fixation of carbon dioxide by rubisco during the Calvin Cycle

Oxygen gas is produced when G3P molecules are combined to make other organic molecules.

Which of the following statements best explains how the energy in a photon of light is stored in a molecule of the sugar G3P?

Light energy energizes electrons to make ATP and NADPH, which provide energy to produce G3P in the Calvin cycle.

Light energy directly provides energy to ATP synthase, which produces ATP during the light reactions.

Light energy directly provides energy to RuBP and CO2, which produce G3P in the Calvin cycle.

Light energy energizes electrons to make G3P, which provide energy to produce ATP and NADPH in the Calvin cycle.

Chemiosmosis in chloroplasts involves which of the following processes?

diffusion of electrons through the thylakoid membrane

reduction of water to produce oxygen

establishment of a proton gradient across the thylakoid membrane

formation of glucose from carbon dioxide

Use the figure and the compounds labeled A, B, C, D, and E to answer the following question.
Which best describes where the ATP for Phase 3 most likely comes from?

oxidative phosphorylation

glycolysis

cyclic photophosphorylation

linear photophosphorylation

What is the primary function of the Calvin cycle?

to produce oxygen by oxidizing water

to regenerate ATP for use in the light reactions of photosynthesis

to produce carbon dioxide for use in the light reactions of photosynthesis

to produce simple sugars from carbon dioxide

An early step in the process of carbon fixation combines three molecules of CO2 with three molecules of RuBP to produce three 6-carbon molecules, which are immediately converted to six 3-carbon molecules. These six molecules are phosphorylated and reduced to produce glyceraldehyde 3-phosphate (G3P). What additional events occur to complete the Calvin cycle?

release of two G3P to make sugars and regeneration of ATP from ADP

release of one G3P to make sugars and regeneration of RuBP

release of one G3P to make sugars and regeneration of citrate

release of one G3P to make sugars and regeneration of NADPH from NADP+

The figure shows the absorption spectrum for chlorophyll a and the action spectrum for photosynthesis. What colors of light are least effective would not be used for photosynthesis?

green-yellow

violet blue

yellow-orange

orange-red

Leo hikes in the woods. He finds a pine cone on the bike trail. What can Leo conclude about the type of plant that produced the cone?

It is a vascular plant

It is a Pterophyte

It is an angiosperm

It is a bryophyte

Which of the following is not a type of vascular plant?

gymnosperms

ferns

mosses

angiosperms

Bryophytes are_________________plant.

Seeded

Non-Vascular

Vascular

Flowering

What classification do these orquids belong to?

gymnosperm

angiosperm

fern

bryophytes

The visible spectrum is from just under 400 nm to just over 700 nm.  What type of waves would have wavelengths longer than 700 nm?

radio and gamma waves

microwaves and infrared

infrared and ultraviolet

x rays and gamma waves

#8 is collectively known as  ___________________________.  It is where most of the photosynthetic activity takes place.

cytoplasm

mesophyll

stomata

grana

thylakoid

The role of the part labeled #1 is

to perform photosynthesis

to allow gas exchange

to release water through epidermal cells

to capture light energy

to prevent the release of water through the epidermal cells

This is an image of a chloroplast.  What is #6 pointing to?

grana stack

cytoplasm

stroma

thylakoids

Above is an image of a thylakoid.  A and C are the photosystems, as shown by the green pigments on their surface.  E is where hydrogen ions DIFFUSE down their gradient.  E is therefore the

NADP reductase

Rubisco

ATP synthase

Electon Transport Chain

When NADPH becomes NADP+, the energy released is provided to the molecules of the Calvin Cycle to power the reactions there.  It would be most appropriate to say that

NADP+ got reduced at the Calvin Cycle

NADP+ got oxidized at the Calvin Cycle

NADPH got oxidized at the Calvin Cycle

NADPH got reduced at the Calvin Ccyle

What accurately describes the flow of the H+ from water?

water --> photosystem II --> photosystem I --> NADPH

water --> Calvin cycle --> photosystem II --> ATP synthase

water --> photosystem I --> photosystem II --> NADPH

water --> photosystem I --> NADPH --> photosystem II --> G3P

Which part would be considered a female part of the flower?  Choose all that apply

A

B

C

D

E

In which part of the flower would you find a male gamete? Give the most specific answer.

A

B

C

D

E

Which part of the flower would eventually become a fruit?

A

B

C

D

E

The oxygen atoms that end up in G3P or other glucose derivitives came from which molecule?

CO2

H2O

RuBP

NADPH

Which statements best describes why plants perform both cyclic and noncyclic photophosporylation

The plant can choose which set of reactions to follow, based on environmental conditions like wind or drought.

Different types of plants perform the different reactions - some plants would perform cyclic, while others have evolved to perfom non-cyclic reactions.

Extra ATP is needed, above the amounts created by non-cyclic light dependent reactions

Extra NADPH is needed, above the amounts creatd by the non-cyclic light dependent reactions

In the vascular bundle of a plant you would find specialized ______ cells for water transport and specialized ________ cells for sugar transport.

cuticle ; mesophyll

xylem ; phloem

cuticle ; epidermal

mesophyll ; guard

phloem ; xylem

Photosynthesizes have evolved to have more than one type of pigment molecule. Why was this an advantage for?

It was not an advantage, it happened accidentally and does not provide an advantage.

Since pigment molecules are broken down to harness their potential energy for the dark reactions of photosynthesis, the more pigment molecules the plant has the more sugar it can make.

Having accessory pigments increases the range of wavelengths and thus energy a plant can get from the suns’ radiation.

Chlorophyll is a very weak molecule that only absorbs green wavelengths, so plants require accessory pigments otherwise they would not be able to create enough food to survive.

This is a false statement, each type of organisms has one type of pigment molecule.

HB Unit 5 Exam 2021

HB Unit 5 Exam 2021

In your own words, describe why this flower shown here is seen as red. Use all appropriate vocabulary.

Describe one possible reason that you learned in class as to why there are such brilliant colors in the fall foliage. Be specific and use all appropriate vocabulary.

Rubisco is an important enzyme in photosynthesis. In your own words, describe- WHERE it is- WHAT it does- what its SUBSTRATE and PRODUCTS would be

Some flowers self-pollinate, and some cross-pollinate. Define each. What is the benefit to the plant of cross-pollination?

Which of the following best describes how oxygen gas is produced during photosynthesis?

Which of the following statements best explains how the energy in a photon of light is stored in a molecule of the sugar G3P?

Chemiosmosis in chloroplasts involves which of the following processes?

Use the figure and the compounds labeled A, B, C, D, and E to answer the following question. Which best describes where the ATP for Phase 3 most likely comes from?

What is the primary function of the Calvin cycle?

The figure shows the absorption spectrum for chlorophyll a and the action spectrum for photosynthesis. What colors of light are least effective would not be used for photosynthesis?

Leo hikes in the woods. He finds a pine cone on the bike trail. What can Leo conclude about the type of plant that produced the cone?

Which of the following is not a type of vascular plant?

Bryophytes are_________________plant.

What classification do these orquids belong to?

The visible spectrum is from just under 400 nm to just over 700 nm. What type of waves would have wavelengths longer than 700 nm?

#8 is collectively known as ___________________________. It is where most of the photosynthetic activity takes place.

The role of the part labeled #1 is

This is an image of a chloroplast. What is #6 pointing to?

Above is an image of a thylakoid. A and C are the photosystems, as shown by the green pigments on their surface. E is where hydrogen ions DIFFUSE down their gradient. E is therefore the

When NADPH becomes NADP+, the energy released is provided to the molecules of the Calvin Cycle to power the reactions there. It would be most appropriate to say that

What accurately describes the flow of the H+ from water?

Which part would be considered a female part of the flower? Choose all that apply

In which part of the flower would you find a male gamete? Give the most specific answer.

Which part of the flower would eventually become a fruit?

The oxygen atoms that end up in G3P or other glucose derivitives came from which molecule?

Which statements best describes why plants perform both cyclic and noncyclic photophosporylation

In the vascular bundle of a plant you would find specialized ______ cells for water transport and specialized ________ cells for sugar transport.

Photosynthesizes have evolved to have more than one type of pigment molecule. Why was this an advantage for?

In your own words, describe why this flower shown here is seen as red. Use all appropriate vocabulary.

Describe one possible reason that you learned in class as to why there are such brilliant colors in the fall foliage. Be specific and use all appropriate vocabulary.

Rubisco is an important enzyme in photosynthesis. In your own words, describe- WHERE it is- WHAT it does- what its SUBSTRATE and PRODUCTS would be

Some flowers self-pollinate, and some cross-pollinate. Define each. What is the benefit to the plant of cross-pollination?

Rubisco is an important enzyme in photosynthesis. In your own words, describe
- WHERE it is
- WHAT it does
- what its SUBSTRATE and PRODUCTS would be

Use the figure and the compounds labeled A, B, C, D, and E to answer the following question.
Which best describes where the ATP for Phase 3 most likely comes from?

In the vascular bundle of a plant you would find specialized cells for water transport and specialized __ cells for sugar transport.

Rubisco is an important enzyme in photosynthesis. In your own words, describe
- WHERE it is
- WHAT it does
- what its SUBSTRATE and PRODUCTS would be
