2.1 - Motion Maps
star
star
star
star
star
Last updated about 3 years ago
7 questions
2
What was the position of object A after 6 seconds?
What was the position of object A after 6 seconds?
2
What was the position of object B after 2 seconds?
What was the position of object B after 2 seconds?
4
What was the velocity of object A?
What was the velocity of object A?
4
What was the velocity of object B?
What was the velocity of object B?
2
Which object was traveling away from the reference point?
Which object was traveling away from the reference point?
6
Draw object C into the motion map. Object C should be traveling in the negative direction at 3m/s for 3seconds. Stop at position 4 for 3seconds; before continuing in the negative direction at 3m/s.
Draw object C into the motion map. Object C should be traveling in the negative direction at 3m/s for 3seconds. Stop at position 4 for 3seconds; before continuing in the negative direction at 3m/s.
4
Create a Motion Map from scratch to fit the following situation:
The ball rolled backward at 4m/s for 3s. It then stopped for 7s. And then the ball traveled forward at 6m/s for 2s.
Create a Motion Map from scratch to fit the following situation:
The ball rolled backward at 4m/s for 3s. It then stopped for 7s. And then the ball traveled forward at 6m/s for 2s.
