Timber knowledge - FEWTEL

Last updated almost 4 years ago

6 questions

Instructions

Required

1

Required

1

Required

1

Required

1

Required

1

Required

1

This task will help you undersatnd the face, edge, width, thickness, end, length and grain direction of a material

Question 1

1.

Identify the area that shows the thickness dimension on this image

Question 2

2.

Identify the area that shows the width dimension on this image

Question 3

3.

Identify the area that shows the going with the grain on this image

Question 4

4.

Identify the area that shows the going against the grain on this image

Question 5

5.

Identify the area that shows the going across the grain on this image

Question 6

6.

Identify the area that shows the face of the timber on this image
