On April 18, 1906, at 05:12 AM PST, a powerful earthquake with a magnitude of 7.9 struck the San Francisco area in California. The disaster led to devastating fires that lasted for several days, resulting in over 3,000 deaths and the destruction of more than 80% of the city. This earthquake is the deadliest in U.S. history and has the highest death toll from a natural disaster in California. While the earthquake and its aftershocks were damaging, the subsequent fires caused by ruptured gas mains were far more catastrophic, destroying approximately 25,000 buildings and costing an estimated $350 million at the time, equivalent to $8.9 billion today.

Required

Warm up: What do you think a builder could do to make a house less likely to fall down in an earthquake?

Click here to open the Earthquake-Proof Homes Gizmo
Select Earthquake

Read a little about San Francisco and faults and click Next

Select Location 1 - Bedrock

In the lower left-hand corner, click and drag House A from the Saved houses to the center of the screen.

Required

Predict: Your first house will be built on bedrock, or layers of solid rock below the soil. House A is a basic house.

What do you think will happen to house A in an earthquake?

Required

Test: Click Test house and then click Play. After the earthquake, what damage can you see?

Required

Describe: Select Show house interior to see the inside of the house. What damage do you see inside the house?

Required

Assess: Select Show damage report. Don’t worry about the different components now. The Score describes how well the house stood up in an earthquake by comparing the cost of repairs to the cost of the house. (100% is great, 0% is bad.) How did the house do?

Cost of repairs: _______
House cost: _______
Score: _______

Required

Now it's your turn!  Can you design an earthquake proof house?

Click Back to Build in the lower left hand corner.

Click Reset house near the top center, then select items from the right side menu.

Foundation: __________
Frame: __________
Walls: __________
Roof type: __________
Roof material: __________

Test: Click Test house and then click Play.

How does the outside of the house look?

How does the inside of the house look?

Select Show damage report. What was the score of your house?

Cost of repairs: _______
House cost: _______
Score: _______

Challenge: Try to build a house with a score above 80%.

If your last house was 80% or higher, try to build the least expensive house that can survive an earthquake.

Click Back to Build in the lower left hand corner.

Click Reset house near the top center, then select items from the right side menu.

Foundation: __________
Frame: __________
Walls: __________
Roof type: __________
Roof material: __________

Test: Click Test house and then click Play.

How does the outside of the house look?

How does the inside of the house look?

Select Show damage report. What was the score of your house?

Cost of repairs: _______
House cost: _______
Score: _______

Conclusion: If you were trying to build an earthquake proof house in real life, what sort of materials and features would you choose? Why would you choose them?

Extend your thinking: Some parts of San Francisco used to be marshes, or wetlands. These areas were filled in with soil to form dry land. This type of ground is called landfill. Houses and even tall buildings are built on landfill in San Francisco.

Would you rather build on bedrock or landfill? Explain your answer.
